OVM6948 Miniature Camera Module Provides High-Quality Imaging for Disposable Medical Guidewires, Catheters and Endoscopes
Color CMOS Analog 40 Kpixel (200 x 200) CameraCubeChip® with OmniBSI™+ Technology
  • SKU

Miniature Camera Module Provides High-Quality Imaging for Disposable Medical Guidewires, Catheters and Endoscopes

OMNIVISION’s OVM6948 CameraCubeChip® is a fully packaged, wafer-level camera module measuring 0.65 mm x 0.65 mm, with a z‑height of just 1.158 mm, ideal for disposable devices operating from the smallest part of the anatomy. The camera module is derived from an ultra small image sensor, the OV6948, winner of the Guinness World Record for “The Smallest Commercially Available Image Sensor*,” with its size of 0.575 mm x 0.575 mm. This complete module can be integrated into a disposable guidewire, catheter or endoscope with a diameter as small as 1.0 mm. With this camera’s small size and high 200 x 200, or 40 KPixel backside-illuminated resolution, high quality images can be captured from within the body’s narrowest blood vessels for neuro, ophthalmic, ENT, cardiac, spinal, urology, gynecology and arthroscopy procedures.

The OVM6948 is the only ultra small “chip on tip” camera with backside illumination, which provides excellent image quality and better low-light performance to help reduce LED heat, along with improved sensitivity. It offers a compact, high quality solution for disposable guidewires, catheters and endoscopes, which are experiencing growing demand because of their ability to reduce cross-contamination risks, downtime inefficiencies and costs associated with the repairs, preprocedural testing and sterilization of reusable endoscopes. Benefiting from the sensor’s low power consumption of a mere 25 mW, less heat is generated for better patient comfort and flexible procedure durations.

Other key features of this camera module include a wide 120-degree field of view and an extended focus range of 3 mm to 30 mm. Its image array is capable of capturing 200 x 200 resolution images and video at up to 30 frames per second, and its analog output that can transmit over 4 meters with minimal noise.

*Current Guinness World record title issued to OMNIVISION Technologies, Inc.: Smallest Commercially Available Image Sensor. The smallest commercially available image sensor is the OV6948, measuring 0.575 mm x 0.575 mm x 0.232 mm, made by OMNIVISION Technologies, Inc. (USA). The record is based on product testing and market research carried out by Transparency Market Research in Pune, India, on 10 April 2019.

June 12, 2018: OMNIVISION and Myriad Fiber Announce World’s First Commercial Endoscopic Surgery Tool Prototype with Integrated Camera

June 12, 2018: OMNIVISION and BioVision Announce Turnkey Medical CMOS Camera Platform for Disposable, In-Office Endoscopy

October 22, 2019: OMNIVISION Announces Guinness World Record for Smallest Image Sensor and New Miniature Camera Module for Disposable Medical Applications

November 16, 2020: OMNIVISION and Almalence Add SuperResolution to World’s Smallest Camera Module for Endoscopic Medical Imaging

Optical size of 1/36″


AntLinx™ Analog output

Low power consumption

Single 3.3V power supply

OmniBSI™+ pixel structure using 0.11 µm process

  • Spec
  • Analog / Digital
  • Category
    200 x 200
  • CFA (Chroma)
    RGB Bayer
  • Frame Rate
    Full @ 30 fps
  • Image Area
    364 x 364 µm
  • Interface
    Analog, AntLinx™
  • Optical Format
  • Output Format
    AntLinx™ Analog
  • Package
    Black Coating
  • Pixel Size
    1.75 µm
  • Power Requirement
    25 mW (with IO consumption)
  • Resolution
    200 x 200
  • Shutter Type
    Rolling Shutter
  • Technology
    AntLinx™, OmniBSI™+
  • Use Case
    Brain / Eyes / Heart / Spine - Angioscope, Brain / Eyes / Heart / Spine - Encephaloscope, Brain / Eyes / Heart / Spine - Neuroendoscope, Brain / Eyes / Heart / Spine - Ophthalmoscope, Dental Mirror, Musculo-skeletal - Arthroscope, Stomach and Intestine - Proctoscope, Urology and Gynaecology - Choledochoscope, Urology and Gynaecology - Cystoscope, Urology and Gynaecology - Hysteroscope, Urology and Gynaecology - Utero-renoscope
  • Operating Temperature
    -20°C to +70°C
  • Package Dimensions
    650 x 650 x 1158 µm
  • Technology
