Overview

The OV7740 (color) CameraChip™ sensor is a low power, high sensitivity VGA CMOS image sensor that provides the full functionality of a single-chip VGA camera in a small footprint.

Using OmniVision's proprietary OmniPixel3-HS™ technology, the 1/5-inch OV7740 boasts a best-in-class low light sensitivity of 6.0 V/lux-sec, making it ideal for integrated notebook cameras, as well as stand-alone PC webcams, security and gaming applications.

The OV7740 can operate at 30 frames per second (fps) in VGA resolution and 60 fps in QVGA resolution with complete user control over image quality, formatting and output data transfer. It supports a digital video parallel port, and provides full-frame, sub-sampled, windowed or scaled 8-bit/10-bit RAW RGB and 8-bit YUV images.

All required image processing functions including exposure control, gamma, white balance, color saturation, hue control, defective pixel canceling, noise canceling, etc., are programmable through the serial camera control bus (SCCB) interface.

In addition, the OV7740 uses proprietary technology to improve image quality by reducing or eliminating common lighting/electrical sources of image contamination, such as fixed pattern noise and smearing, to produce a clean and fully stable color image.

For storage purposes, the OV7740 also includes one-time programmable (OTP) memory.

Features

Support for output formats:
- RAW RGB
- YUV

Support for image sizes:
- VGA
- QVGA
- CIF and any size smaller

Support for black sun cancellation

Support for internal and external frame synchronization

Standard SCCB serial interface

Digital video port (DVP) parallel output interface

Embedded one-time programmable (OTP) memory

On-chip phase lock loop (PLL)

Embedded 1.5V regulator for core

Part Specification
SpecOV07740-A32AOV07740-G00A
PackageCSPCOB
TechnologyOmniPixel3-HS™OmniPixel3-HS™
InterfaceDVPDVP
Shutter TypeRolling ShutterRolling Shutter
ResolutionVGAVGA
CFA (Chroma)RGB BayerRGB Bayer
Analog / DigitalDigitalDigital
Power RequirementActive: 48 mA
Standby: 20 µA
Active: 48 mA
Standby: 20 µA
Output FormatYUV
RAW
YUV
RAW
Operating Temperature-30°C to +70°C-30°C to +70°C
Optical Format1/5"1/5"
Frame RateFull @ 30 fpsFull @ 30 fps
Pixel Size4.2 µm4.2 µm
Image Area2755.2 x 2049.6 µm2755.2 x 2049.6 µm
Package Dimensions4185 x 4345 µm4200 x 4360 µm
Product GuidePDFPDF
