OVMed® ISP - Image Processing Unit

The OVMed® is OMNIVISION’s latest advanced Image Processing Unit (IPU) for endoscopic and catheter applications.

The key value add of OVMed® are:

  • Optimized, industry-leading feature set and image quality
  • Cost effective
  • Customer resource optimization allows customer to focus on differentiated post-processing algorithms
  • Quick time to market: Full turnkey solution; already integrated with camera modules
  • Compact form factor fits into small devices
  • Low power: USB powered
  • User configurable: 7 hardware buttons can be defined by customer application
  • SDK: easy for customers to develop their own application software



OVMed® ISP – Image Processing Units
Spec OH1093 OH0116 OH0117 OH0118 OH0130
Image Sensors Supported OVM6946
OV6946
OVM6946
OV6946
OVM6946
OV6946
OVM6946
OV6946
OH01A10
OCHSA10
Input RAW Bayer
Analog
RAW Bayer
Analog
RAW Bayer
Analog
RAW Bayer
Analog
MIPI
Output YUV 422
USB2.0
RAW 8/10
RAW 8/10
YUV 422
USB2.0
DVP
YUV 422
RAW 8/10
YUV 422
HDMI
USB3.0
ISP ASIC ASIC ASIC FPGA ASIC
OS / SDK SDK – Windows SDK – Windows SCCB command set Adjustment tool SDK
Dimensions 86 x 35 x 8 mm 60 x 15 x 8 mm 36 x 13 x 2.8 mm 86 x 35 x 15 mm 100 x 22 mm
Target Product Camera Control Unit (CCU) Endoscope Handle
Camera Control Unit (CCU)
Endoscope Handle
Camera Control Unit (CCU)
Camera Control Unit (CCU) Endoscope Handle
Camera Control Unit (CCU)
Power Consumption 300 mA 300 mA 300 mA 500 mA Less than 350 mA
Product Guide PDF PDF PDF PDF PDF

Integrated design: sensor, processor bridge, ISP, and PC interface

Small form factor to fit space constrained equipment

Easily adjustable system parameters with pre-defined buttons

Advanced ISP delivers high quality images

Ready-to-use Software Development Kit (SDK) to facilitate IP integration

Seamless evaluation and build with customer equipment

Market-ready, end-to-end solution

Software compatibility with Windows, Linux, and Android platforms
