OMNIVISION’s OV20880 is an ultra-compact image sensor designed specifically to bring 20 megapixel resolution to high-end, dual-camera mobile zoom solutions using OMNIVISION’s second-generation, 1.0‑micron PureCel®Plus-S pixel technology. The OV20880 offers advanced features such as zig-zag high dynamic range (zHDR), phase detection autofocus (PDAF), and support for dual-camera functionality with context switching, scaler and electronic image stabilization (EIS). The on-chip EIS also enables advanced capabilities such as image deblur.
zHDR uses a long and a short exposure in a single frame to extend dynamic range capabilities of the sensors. Long and short exposure lines are diagonally interlaced across the entire pixel array in a zig-zag pattern. This enables live preview and video recording in HDR mode and single-shot full-resolution HDR images in capture mode without any shutter lag.
The OV20880 captures full-resolution 20 megapixel images and video with zHDR capability at 30 fps, ultra-high-resolution 4K2K video with full field-of-view at 60 fps, and 1080p high definition (HD) video at 120 fps. The OV20880 offers both MIPI D-PHY and C-PHY interfaces.
The OV20880 comes in a package size of 8.5 x 8.5 mm with a z-height of 5.3 mm.
Automatic black level calibration (ABLC)
Programmable controls for:
– Frame rate
– Mirror and flip
– Cropping
– Windowing
Support for dynamic DPC cancellation
Supports output formats:
– 10-bit RAW RGB
– DPCM 10-8 compression
Supports horizontal and vertical subsampling
Supports typical images sizes:
– 5184 x 3888
– 3840 x 2160
– 2560 x 1440
– 1920 x 1080
– 1280 x 720
– 1000 x 568
– 800 x 480
Programmable I/O drive capability
Standard serial SCCB interface with speed up to 1 MHz (when clock input is >10 MHz)
Up to 4-lane MIPI TX interface with speed up to 1.92 Gbps/lane
Embedded 20 kbits of one-time programmable (OTP) memory
Sequential multi-frame HDR and ZigZag HDR support
Phase detection auto focus (PDAF) pixels with bypass PD pixels
Gyro interface with 4-wire SPI and EIS support
Long exposure time of up to 30 seconds
Two on-chip phase lock loops (PLLs)
Built-in temperature sensor
Typical module size: 8.5 x 8.5 x 5.3 mm
-
