OC02C Industry’s Smallest 1080p Full HD Image Sensor for High Performance Video Communication in Thin Bezel Notebooks and Tablets
1/7.25" Color 2‑Megapixel (1920 x 1080) CMOS Image Sensor with PureCel®Plus‑S Technology
  • SKU
    OV02C10-GA5A-001A
    OV02C1B-GA5A-001A
    OV02C10-A21A-001A
  • Package
    COB, RW
    COB, RW
    CSP

Industry’s Smallest 1080p Full HD Image Sensor for High Performance Video Communication in Thin Bezel Notebooks and Tablets

OMNIVISION’s OV02C is a 1/7-inch, 2 megapixel image sensor for full high definition (HD) video performance in thin bezel premium notebooks, tablets and IoT devices. The OV02C is a full-featured image sensor that combines superior video performance and ultra-low power in a miniature size for high screen-to-body ratio designs. The sensor combines smaller pixel size and high resolution in the smallest form factor, enabling the most vivid quality video and image capabilities. The sensor offers 60 frames per second (fps) and excellent pixel performance in the thinnest 3 mm module Y size for high screen-to-body ratio designs.

Built on OMNIVISION’s PureCel®Plus-S stacked die technology, the OV02C enables high functionality in the smallest die size. This next-generation pixel technology also provides higher color fidelity and excellent low light sensitivity, along with a high signal-to-noise ratio of 37.5 dB for crisper images. Additionally, PureCel®Plus-S provides higher full well capacity, zero blooming and lower power consumption.

The OV02C’s “Always On” feature senses user presence in ultra-low-power mode and the system can be locked and woken up touchlessly, extending the lifetime of the battery. The OV02C also supports multi-camera synchronization and multi-frame HDR at 30 fps real time video streaming.

May 25, 2021: OMNIVISION Launches the Industry’s Smallest 1080p Full HD Image Sensor for High Performance Video Communication in Thin Bezel Notebooks and Tablets

1.116 μm x 1.116 μm pixel

Optical size of 1/7.25″

34° CRA

2MP at 60 fps

Programmable controls for:
– Frame rate
– Mirror and flip
– Cropping
– Windowing

Supports images sizes:
– 2MP (1920×1080)
– 720p (1280×720)
– VGA (640×480), and more

Support for output formats: 8-bit or 10-bit RGB RAW

Two-wire serial bus control (SCCB)

MIPI serial output interface (1-lane or 2-lane) / 2-wire serial output

Two on-chip phase lock loops (PLLs)

2x binning support

Image quality controls:
– Defect pixel correction
– Automatic black level calibration

Suitable for module size of 4 x 3.5 x 2 mm

  • Spec
    OV02C
  • Analog / Digital
    Digital
  • Category
    2MP to 5MP
  • CFA (Chroma)
    B&W, Color
  • Frame Rate
    Full @ 60 fps
  • Image Area
    2160.576 × 1223.136 μm
  • Interface
    MIPI
  • Optical Format
    1/7.25"
  • Output Format
    8-bit in 2-wire serial interface, 8/10-bit RGB RAW MIPI
  • Package
    COB, CSP, RW
  • Pixel Size
    1.116 µm
  • Power Requirement
    Active: 115.4 mW, Standby: 0.25 mA, XSHUTDOWN: 1 µA
  • Resolution
    2MP
  • Shutter Type
    Rolling Shutter
  • Technology
    PureCel®Plus‑S
  • Use Case
    IoT Devices, Notebooks, Tablets
  • Operating Temperature
    -30°C to +85°C
