High-Performance, Low-Power 2K 4‑Megapixel CMOS Image Sensor for Consumer Security and Surveillance Cameras

The OS04D10‑1C is a 4‑megapixel (MP) image sensor that brings 2K resolution digital images and high-definition (HD) video at 30 frames per second (fps) to IP and HD analog security cameras, including smart home, doorbell and baby monitoring devices. The OS04D10‑1C CMOS image sensor utilizes a high-performance backside-illuminated (BSI) pixel while also providing 40% power consumption savings, as well as improvements of over 30% in signal-to-noise ratio (SNR1) and 40% in sensitivity when compared with its predecessor.

The OS04D10‑1C image sensor’s 2.0‑micron (µm) BSI pixel is based on OMNIVISION’s PureCel®Plus technology and enables higher sensitivity, ultra-low noise and better overall image quality. Select conversion gain (SCG) allows the sensor to flexibly select low and high conversion gain depending on the lighting conditions. On‑chip auto explorer control (AEC) and auto gain control (AGC) further accelerate system-on-chip (SoC) booting time. Low power consumption is beneficial for battery operated devices, especially doorbell security cameras. It comes in a cost-effective 1/3.067‑inch optical format and is pin-to-pin compatible with OMNIVISION’s OS04L image sensor as well as other new products that will be launched in the future.

The OS04D10‑1C supports MIPI interfaces.
