1/7.5" B&W VGA (640 x 480) CMOS Image Sensor with OmniPixel®3‑GS and Global Shutter Technologies
  • SKU
    OG0VE1B-A25A-001A
    OG0VE1B-GA4A-001A
  • Package
    25-pin CSP
    COB, RW

New-Generation Global Shutter CMOS Image Sensor for Mainstream AR/VR/MR and Metaverse

The OG0VE global shutter (GS) CMOS image sensor is a small-form-factor, high-sensitivity device for AR/VR/MR, metaverse, machine vision, and barcode scanner applications.

The OG0VE image sensor has a sensitive 3.0‑micron pixel based on OMNIVISION’s OmniPixel®3‑GS technology. The sensor’s global shutter pixel architecture and excellent low-light sensitivity allow it to be used for any application requiring simultaneous localization and mapping (SLAM), gesture detection, head and eye tracking, and depth and motion detection.

The OG0VE has 640 x 480 resolution and comes in a 1/7.5‑inch optical format. It has very low power consumption, at less than 34 mW when running at 60 frames per second (fps) with VGA.

The sensor supports one-lane MIPI D‑PHY at up to 800 Mbps. It comes in OMNIVISION’s CSP package or as bare die.

December 6, 2022: OMNIVISION Unveils New-Generation Global Shutter Image Sensor for Mainstream AR/VR/MR and Metaverse

3.006 μm global shutter pixel

Automatic black level calibration (ABLC)

Programmable controls for:
– Frame rate
– Mirror and flip
– Cropping
– Windowing

Supports output formats: 8/10-bit RAW

Supports images sizes:
– 640 x 480
– 400 x 400
– 200 x 200
– 100 x 100

Fast mode switching

Supports horizontal and vertical 2:1 and 4:1 monochrome subsampling

Supports 2×2 monochrome binning

One-lane MIPI serial output interface

Embedded 256 bits of one-time programmable (OTP) memory for part identification, etc.

Two on-chip phase lock loop (PLL)

Programmable I/O drive capability

PWM

Built-in strobe control

  • Spec
    OG0VE
  • Analog / Digital
    Digital
  • Category
    1MP and Below
  • CFA (Chroma)
    B&W
  • Frame Rate
    Full @ 120 fps
  • Interface
    MIPI
  • Optical Format
    1/7.5"
  • Output Format
    8/10-bit RAW
  • Package
    COB, CSP, RW
  • Pixel Size
    3.006 µm
  • Resolution
    VGA
  • Shutter Type
    Global Shutter
  • Technology
    Global Shutter, OmniPixel®3‑GS
  • Use Case
    3D Imaging, AR Applications - GS camera for eye tracking, AR Applications - GS camera for SLAM, AR/VR Cameras, Biometric Authentication, Gaming, Industrial Automation, Industrial Bar Code Scanning, Machine Vision
