OCHFA10 1/17.5" color CMOS analog 518 Kpixel (720 x 720) CameraCubeChip® with PureCel®Plus-S technology
1/17.5" Color CMOS Analog 518 Kpixel (720 x 720) CameraCubeChip® with PureCel®Plus‑S Technology
  • SKU
    OCHFA10-RAJA-001A-Z

Color CMOS Analog 518 Kpixel (720 x 720) CameraCubeChip® for Disposable Endoscopic Cameras

OMNIVISON’s OCHFA10 CameraCubeChip® is a 1/17.5” color 518 Kpixel analog camera for the rapidly growing disposable medical endoscope market. It is the same size as the OVM6946 but has higher resolution, and is an ideal upgrade for bronchoscopes, ureteroscopes and hysteroscopes. It can also be used for industrial borescopes.

The OCHFA10 CameraCubeChip® integrates the image sensor, processor, and lenses in a miniature wafer-level camera module. It features OMNIVISION’s PureCel®Plus-S pixel technology, enabling high functionality in the smallest possible die size. With 720 x 720 resolution at 30 frames per second, it provides the best image quality for improved patient outcomes.

November 3, 2021: OMNIVISION Announces Industry’s Highest-Resolution Image Sensor for ENT, Cardiac, Arthro, OB-GYN and Utero-Renal Endoscopes

Optical size of 1/17.5″

AntLinx™ Analog output

Single 3.3V power supply

On-chip PLL

Serial peripheral interface (SPI)

Exposure and gain control

Pseudo-global shutter (LED mode)

PureCel®Plus-S pixel structure

Improved sensitivity, FWC, zero blooming, low noise, and low power consumption

Enhanced NIR sensitivity

Square aspect ratio

Minimum package size (total 4 pads)

Non-autoclavable

4 m drive distance

  • Spec
    OCHFA10
  • Analog / Digital
    Analog
  • Category
    720 x 720
  • CFA (Chroma)
    Color
  • Frame Rate
    Full @ 30 fps
  • Image Area
    733.824 x 733.824 μm
  • Interface
    Analog
  • Optical Format
    1/17.5"
  • Output Format
    AntLinx™ Analog
  • Package
    Black Coating
  • Pixel Size
    1.008 µm
  • Power Requirement
    25 mW (with IO consumption)
  • Resolution
    720 x 720
  • Shutter Type
    Pseudo-Global Shutter (LED Mode)
  • Technology
    PureCel®Plus-S
  • Use Case
    Brain / Eyes / Heart / Spine - Angioscope, Brain / Eyes / Heart / Spine - Encephaloscope, Brain / Eyes / Heart / Spine - Neuroendoscope, Brain / Eyes / Heart / Spine - Ophthalmoscope, Brain / Eyes / Heart / Spine - Spinoscope, Ear / Nose / Throat and Airway Management - Bronchoscope, Ear / Nose / Throat and Airway Management - Esophagoscope, Ear / Nose / Throat and Airway Management - Laryngoscope, Ear / Nose / Throat and Airway Management - Mediastinoscope, Ear / Nose / Throat and Airway Management - Otoscope, Ear / Nose / Throat and Airway Management - Pleuroscope, Ear / Nose / Throat and Airway Management - Rhinoscope, Ear / Nose / Throat and Airway Management - Thoracoscope, Musculo-skeletal - Arthroscope, Stomach and Intestine - Duodenoscope, Stomach and Intestine - Proctoscope, Urology and Gynaecology - Amnioscope, Urology and Gynaecology - Choledochoscope, Urology and Gynaecology - Cystoscope, Urology and Gynaecology - Hysteroscope, Urology and Gynaecology - Nephroscope, Urology and Gynaecology - Utero-renoscope
  • Operating Temperature
    -20°C to +70°C
  • Package Dimensions
    1075 x 1075 x 2241 μm
  • Category
    1MP and Below
