Panel System Integration Controller (PSIC) for 1920 x 1080 / 1200 / 1280 Panels
  • SKU
    CRX2000AC-A0S-EGVDAZ-0
    CRX2000AC-A0S-EGVCAG-0

T-CON Embedded Driver IC for Next-Generation Notebook Display

OMNIVISION Display Solutions’ CRX2000A T‑CON embedded driver IC (TED IC) is designed for 2160 x 1350 (LTPS), 1920 x 1080 / 1200 / 1280 (a‑Si, Oxide, and LTPS) LCD TFT panels and is the best fitted solution for low cost and low power consumption. CRX2000A can be mounted on COG (chip on glass) area and supports 1/2/4 lanes eDP 1.4b MSO (multi-SST operation) input interface with HBR, R243, R216 and RBR, and 2880ch source driver output.

CRX2000A provides a 1‑chip solution for a‑Si, Oxide, and LTPS panels. It can also support a 2‑chip solution for panels with VESA MSO feature, up to 2880 x 1920 with a‑Si dual gate or LTPS MUX2/3.

CRX2000A supports an external I2C EEPROM read/write function. It also supports accessing internal registers by eDP I2C-over-aux, I2C. An SDK (system development kit) is available to enable fast light-up, fine-tune and optimize panel performance for customers.

Common features:
– Power supply
○ Logic supply voltage: 1.2V
○ LCD driving voltage: AVDD 4.0V ~ 6.0V, AVEE -6.0V ~ -4.0V
○ IOVCC 3.0V ~ 3.6V
○ Output dynamic range: -5.4V (>AVEE+0.2V) to GNDA-0.2, GNDA+0.2 to 5.4V (<AVDD-0.2V)
○ VGH supply voltage +8V ~ +20V
○ VGL, VGLp supply voltage -7V ~ -12V
○ VGH-VGL must be less than 32V
– COG package
– Operation temperature: -20°C ~ +85°C

eDP features:
– Support the following bit rate mode: HBR (2.7 Gbps), R243 (2.43 Gbps), R216 (2.16 Gbps), RBR (1.62 Gbps)
– Support main link Vdiff: 200 mV (min)
– Support 1 and 2 lanes main link configuration
– Support full link training and fast link training
– Support MSO (multi-SST operation)
– High noise tolerant eDP PHY working on COG
– Support AdaptiveSync, FreeSync
– Support I2C-over-aux
– Support DisplayPort standard SSC 0.5% down-spreading

T‑CON block features:
– Programmable GIP signals up to 42 outputs for GIP panel (left x21, right x21)
– Support SDK (system development kit to light-up, debug and fine-tune easily)
– Support APPS (advanced panel power saving) function that is PSR-like function without frame buffer
– Support I2C serial port interface master/slave
– Support 18/24‑bit RGB input
– Digital gamma
– Color management
– Noise avoidance for touch panel
– Support panel BIST mode
– Support CABC
– Support eDP MSO

GIP features:
– Programmable GIP signals up to 42 outputs for GIP (left x21, right x21)
– Integrated level shifter
– Support single gate, dual gate driving method
– EQ function of GIP output

Source driver features:
– 2886/2880/2166/2160/1926/1920 output channels
○ 2880ch: 1920 x 1280, 1920 x 1200, 1920 x 1080 for a‑Si single gate (2‑chip) or dual gate (1‑chip)
– 8‑bit resolution / 256 gray scale
– Dot (1/2 dots) and N‑line (N=1/2/4) inversion display function provided
– Repair amplifier
– Embedded gamma buffers
– Adjusting gamma correction
– Low frame rate for saving power consumption
– Contact resistance measurement
– XAO signal from PMIC
– Voltage detector: 4 voltage setting of IOVCC
– GAS (gate all select) function for preventing image sticking when abnormal power off
– Register control function
○ Output channel select function
○ Line-repair amp enable
○ Programmable gamma function
○ Source output chopper control
○ Gamma output chopper control
○ Source driving control for power saving

  • Spec
    CRX2000A
  • Frame Rate
    60 Hz
  • Interface
    eDP
  • Package
    COG
  • Panel Type
    a-Si, LTPS, Oxide
  • RAM
    No PSR
  • Resolution
    1920 x 1200
