Color CMOS 640 Kpixel (800 x 800) OVMed® Cable Module with PureCel®Plus-S Technology

SKU

OCHSA OVMed® Cable Module

OVMed® Cable Modules Combined with OMNIVISION’s CameraCubeChip® Modules and OVMed® ISP Boards, Provide Complete Medical Imaging Subsystems for Endoscopes and Catheters

OMNIVISION’s OVMed® cable module line of endoscope, catheter and dental cables create a platform, in combination with the company’s portfolio of CameraCubeChip® wafer-level camera modules and OVMed® image signal processor (ISP) boards. As the world’s top supplier of medical imaging components, this addition makes OMNIVISION the industry’s first supplier of complete, end-to-end medical imaging subsystems, enabling medical device OEMs to focus on differentiating their core endoscope and catheter designs, while accelerating time to market and obtaining a competitive materials cost. This single source of supply and support for the entire medical imaging subsystem is also tuned for optimal performance by OMNIVISION’s imaging experts.

OVMed® cable modules provide high image quality with minimal artefacts, for the transmission of captured images from the endoscope’s distal tip, down the endoscope shaft to the proximal end. These cables are optimized for small module size, thin diameter, flexibility, mechanical robustness and cost. Additionally, they are electrically shielded for electromagnetic compatibility (EMC) and interference (EMI), which allows the cables to withstand high energy discharges during multimodal medical imaging procedures inside the body, while eliminating interference with other devices in the operating room.

OMNIVISION’s flexible design and manufacturing model allows the company to provide semi-custom cable solutions based on customer requirements. Customizable parameters include short cables of 2.5 meters or less, long cables up to 5 meters, analog or digital MIPI output from 200 x 200 at 30 fps up to 720p resolution at 60 fps, as well as a wide range of connectors—all with or without LED illumination. In addition, every OVMed® cable module undergoes comprehensive certification, qualification and testing, including testing for banned substances, operation tests, stress tests, sterilization, bio-compatibility and workmanship, making it more suitable for medical devices.

Download Product Guide

Features
Tech Specs

OCHSA10 is a 640 Kpixel (800×800) CameraCubeChip® with PureCel®Plus-S technology based on OH01A10 color CMOS image sensor

Non-autoclavable

Highest resolution in small die size

Best image quality

High frame rate for jitter-free images

PureCel®Plus-S high color fidelity
– High FWC with less saturation
– Best low light sensitivity
– Almost no blooming
– Low noise
– Better color crosstalk
– Higher QE performance

Supports images sizes:
– 800 x 800
– VGA (640 x 480)
– 400 x 400, and more

Single 5.0V power supply for sensor

Individual power supply for LED

Output format can be 8/10-bit RGB RAW

Stereo ready (frame sync)

Sync light source (strobe)

Horizontal and vertical subsampling

Low power:
– More than 25% lower power than previous generation
– Low power mode for subsampling modes (less than 10 mW)

On-chip phase lock loop (PLLs)

2×2 analog binning support

Image quality controls:
– Lens shading
– Denoise
– Manual exposure
– Gain control
– Defect pixel correction
– Automatic black level calibration

Group hold
